应用与详细介绍/Brief Introduction：

机械机器设备适用了异常三通管装罐机械机器设备生产线阀，符合于水剂和膏霜类商品的装罐机械机器设备生产线，特别的对高粘性废料（如浓酱、青椒酱、番茄酱、种衣剂、微乳剂、浮悬剂等）的特效相当突出，且精准高。机械机器设备适用了PLC可程序编程把控，搭配69英寸触模屏组队接口系统化，采取智能进瓶，智能装罐机械机器设备生产线，智能出瓶，电器电线电缆，自动元机器设备构造件均适用了国际级加盟品牌，确定了经验丰富的质理和经久耐用安全的功效。本机械机器设备机器设备构造简洁，操作的非常方便，是境内非常完美的而对高粘性废料的装罐机械机器设备生产线机械机器设备。机械机器设备配齐了以防止渗漏与磨砂机的装罐机械机器设备生产线闷头，确定装罐机械机器设备生产线结束以后后无渗漏，无磨砂机。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

特质/Characteristic：

◆管控软件——应用三凌PLC管控软件，装灌摄入量随机的稍微调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆作业方法菜单栏——6屏幕尺寸彩屏手触式作业方法菜单栏，客观简单、安全性高可以信赖Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆作用提高工作效率——排料有防漏滴平衡装置，可不同货物特征参数要具备下潜包装作用。（此作用是可以适用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器产品构件——均选取亚太口碑好牌子，保持装置的人身好用性、较准性好；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆自动化设备控制零配件——机械设备控制零配件均利用一流304不锈不锈钢板钢板网作,烦请都要学习货物就可以利用316L另计算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算查测——城市热力图运算，对做工作收获量准确呈现。Counting test, real-time, intuitive reflect the yield of work.◆灌装生产线查重——无瓶不灌、瓶数不不灌Bottle filling test - no bottle no filling, not enough◆维保的情况——机器适用GMP的要求，可高效拆除、刷洗维保。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆对换尺寸要求——换成灌装生产线尺寸要求时，只需要容易优化，容易解决。Changing specifications - change the filling specifications, simply adjust, easy fix.◆坏保健康设置——设置了坏保健康结构，使工具的运作自然环境相对的清洁卫生。（此坏保健康设置能够选型）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

科技指标/technical parameters：

分装头数The number of filling head	8头（自选4、6、8、10、1俩✅个分装头）8 head (optional 4, 6, 8, 10, 12 filling head)
适用性瓶径 Applicable bottles Drive	Ф33-Ф100 mm
压力容器检验精确度measure precision	±1%
罐装存储空间Canned capacity	150-1000ml
生產水平Production Capacity	2400-4000瓶/小的时候2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
